35
5.7.8 Manual operation
A transfer to manual operation mode in the selected channel will take place when the parameter HL has been set to On.
The return to the automatic mode can take place in one of the following ways:
" set the parameter HL to OFF
or
" automatically when 60 minutes have elapsed since the transfer into manual operation mode
or
" by restarting the SKF Maxilube hydraulic pos. or the SKF ST-1240-IF CONTROL CENTRE
In manual operation mode, the SET button is used to:
" start pumping
" stop pumping
" transfer pumping to another line
The lubrication program will retain the pressure within the set high limit value in the line being pumped. An oil lubrication
system (lubrication system operating mode 01 or 02) and a progressive system have no pressure monitoring.
IF-105 settings
General
Setpoints are lubrication channel basic values, such as lubrication cycle and maximum pressurisation time. The setpoints
are channel specific.
All settings are password protected.
Entering password
1. Select the code for the setting to be changed on the display with ù.
2. Press SET.
3. The display will show the code PPP.
4. In a moment, the first character of the display will start to blink.
5. Select with
ù the first number of the password on the display.
6. Move to the next character by pressing ø.
7. When you have entered all three numbers of the password, press SET.
8. Once the password has been entered correctly, the code ACC will be displayed and the setpoints can be changed
during the next 10 minutes.
9. If the password has not been entered correctly, the code Err will be displayed and the display will return to normal
mode.
The password for setpoints is 105.
