CONTROLS, INSTRUMENTS AND EQUIPMENT
D.E.S.S. Status
V800 Model
This lamp will light up to
confirm D.E.S.S. status. Refer
to previous paragraphs for
description.
High Beam
All Models
Lights when headlamp is on
HIGH beam.
Engine Overheat Warning
V800 Model
If this lamp glows, reduce
snowmobile speed and run
snowmobile in loose snow or
stop engine immediately.
Low Battery Voltage
V800 Model
This lamp will light up to
indicate a low battery voltage
condition. See an authorized
Ski-Doo dealer as soon as
possible.
Engine Management System (EMS)
V800 Model
This lamp will light up to
indicate a trouble. Refer to
TROUBLESHOOTING
for
trouble code meaning and
remedy.
5) Gear Shift Lever
These models are equipped with a
mechanical reverse controlled by a
4-position gear shift lever.
A29D2JA
TYPICAL
6) Handlebar
The handlebar allows the steering of
the snowmobile. As the handlebar
is rotated to right or left, the skis are
turned right or left to steer the snow-
mobile.
WARNING
Fast reverse while turning, could
result in loss of stability and con-
trol.
Handlebar height is adjustable. See an
authorized Ski-Doo dealer.
7) Mountain Strap
Mountain strap provides a grip for
driver when side-hilling.
WARNING
This strap is not for towing, lift-
ing or other purpose than tempo-
rary use as a grab handle during
side-hilling. Always keep at least
one hand on the handlebar.
_______________
31
