CONTROLS, INSTRUMENTS AND EQUIPMENT
Skandic SWT
To remove backrest, remove retaining
hardware on both sides.
mmo2008-001-020_a
TYPICAL
1. Retaining hardware
Skandic WT
To remove backrest, remove wing
screwonbothsides.
mmo2008-001-021_a
1. Wing screw
All Models
NOTICE
Take care to store back-
rest properly to avoid any damages.
33) Tachometer
Direct-reading dial indicates the num-
ber of thousand of revolutions per
minute (RPM) of the engine.
A33E0AA
TYPICAL — MULTIPLY THE READING BY
1000
34) Adjustable Mirrors
Each mirror can be adjusted to suit
driver's preference.
WARNING
Adjust with vehicle at rest in a safe
place.
WARNING
Objects in mirror are closer than
they appear.
35) Mechanical Fuel Level
Gauge
Located at rear of fuel tank cap, the
gauge facilitates fuel level reading.
A32A25B
1 2
TYPICAL
1. Full
2. Empty
