MAINTENANCE PROCEDURES
Engine Oil (V800 Model)
Engine Oil Level
NOTICE
Check level frequently
and refill if necessary. Do not over-
fill. Operating the engine with an
improper level may severely dam-
age engine. Wipe off any spillage.
mmo2008-001-009_a
RH SIDE OF ENGINE COMPARTMENT
1. Dipstick
Make sure engine is at operating tem-
perature.
Snowmobile must be on a level sur-
face.
Let engine running at idle forat least30
seconds.
Stop engine, remove and wipe the dip-
stick.
Reinstall dipstick.
Remove and check oil level. Oil level
must be between minimum and maxi-
mum marks on dipstick.
There is a capacity of 500 ml
(17 U.S. oz) between the two marks.
mmo2007-001-003_a
1. Maximum
2. Minimum
To add oil, remove dipstick. Place a
funnel into the dipstick tube to avoid
spillage.
Add a small amount of recommended
oil and recheck oil level.
Repeat the above procedures until
oil level reaches the dipstick's upper
mark. Do not overfill.
Properly reinstall dipstick.
Spark Plugs
Spark Plug Removal
1. Open the hood.
2. Carefully remove spark plug wire
cap with a twisting and pulling mo-
tion.
3. Using a proper socket or the spark
plug socket and screwdriver blade
from tool kit, unscrew spark plug a
few turns without removing it.
mmo2008-008-009
1. 19 mm socket
2. Screwdriver rod
4. Clean spark plugs and cylinder
heads.
68
