SPECIFICATIONS
SKANDIC WT
MODEL
550F
STEERING SYSTEM
Ski type ADJ
Toe-out 5 mm (.197 in)
Camber
0°
WEIGHT AND DIMENSIONS
Dry weight WT 285 kg (628.3 lb)
Length 306 cm (120.5 in)
Width 108 cm (42.5 in)
Height 130 cm (51.2 in)
Ski stance (carbide to carbide) 90 cm (35.4 in)
(1)
Measure gap between slider shoe and bottom inside of track when exerting a downward pull to the track.
(2)
Equal distance between edges of track guides and slider shoes.
(3)
Drive belt height must be adjusted every time a new drive belt i
s installed. Confirm drive belt part number
application with an authorized Ski-Doo dealer.
_______________
87
