SPECIFICATIONS
SKANDIC SWT
MODEL
V800
ELECTRICAL SYSTEM
Magneto generator output 460 Watt @ 6000 RPM
Ignition type
CDI (Capacity Discharge Ignition)
by DENSO
Make and type NGK DCPR8E
Spark plug
Gap 0.7 mm to 0.8 mm (.028 in to .031 in)
Battery 12 V, 21 A•h
Headlamp 60/55 Watt (H4)
Taillight and stoplight 8/27 Watt
Fuse Refer to FUSES
DRIVE SYSTEM
Type
XPS SYNTHETIC CHAINCASE
OIL (P/N 413 803 300)
Gearbox oil
Quantity 500 ml (16.9 U.S. oz)
Drive pulley type TRA IV
Drive pulley calibration Clutch engagement 2500 ± 100 RPM
Driven pulley type NDT 6-K VSA
Width 37.3 mm (1.469 in)
Drive belt
Wear limit 35.8 mm (1.409 in)
Deflection 32 mm ± 5 mm (1.26 in ± .197 in)
Drive belt adjustment
Force 11.34kgf (25 lbf)
Width 60 cm (24 in)
Length 396.8 cm (156 in)Track
Profile height 31.8 mm (1.25 in)
Deflection
(1)
40 mm to 50 mm (1-9/16 in to 1 in)
Track adjustment
Force
(1)
7.3 kgf (16 lbf)
_______________
89
