BlueControl Insect
Technical User Guide 41
In order to obtain correct adjustment of the house climate with MultiStep, you must adjust the climate controller
using the ventilation system data:
• Nominal air output of the system in m
3
/h (air requirement of the animals).
• Exhaustion capacity of the stepless exhaustion unit(s)
• Exhaustion capacity of the various steps, MultiStep
When two stepless fans are used, they can be set up to work in
parallel or sequentially.
11.1.3 Network settings
The management program FarmOnline Explorer has access to the controllers through the network of the farm.
If a DHCP server is not available in the network, the names of the individual units integrated in the network are
laid down in a plan, and an IP address is assigned to each unit. All names and IP addresses must be unique.
Thus, the entire network must be described in a plan, so it is possible to distinguish between the individual con-
trollers. See also the FarmOnline Explorer Technical Manual.
Select the menu Technical | Service | Network settings| IP- configuration
MAC address MAC address of the controller. It is, for example, used in connection with error tracing
in the network.
IP configuration mode DHCP or Static IP.
IP address The IP address of the controller: e.g. 192.168.1.101.
Net mask The Netmask of the controller: e.g. 255.255.255.0.
Gateway IP address The Gateway address of the controller: e.g. 192.168.1.1.
Edit IP configuration mode: Selecting Static IP / DHCP
Entering IP address, Netmask and Gateway IP address.
Netmask and gateway must only be set when selecting Static IP.
The controller is set to Static IP by default.
SKOV A/S recommends that you follow a standard network setup (also see FarmOn-
line Explorer Technical manual).
