BlueControl Insect
Technical User Guide 51
12 Troubleshooting instructions
Is there 230 V current on terminals A1+ A2 (if not, check installation fuses and fault current relay)
Is the change-over switch of the fan speed controller MAN/AUT set on AUT?
Is the controller set to automatic control?
Are the temperature sensors OK?
Is the motor relay/switch of the fan OK?
Is the source of heating and its supply OK?
Is the winch motor and its change-over switches OK?
Is the electrical connection of the winch motors correct? See the circuit diagrams; please pay extra attention
to the supply voltage via the relays.
Is the potentiometer of the winch motor adjusted?
Is the controller installed correctly?
12.1 Temperature sensor control table
12.1.1 Table relating to DOL 114 temperature sensor control
°C °F V °C °F V °C °F V
-40 -40.0 0.00 6 42.8 4.60 28 82.4 6.80
-35 -31.0 0.50 7 44.6 4.70 29 84.2 6.90
-30 -22.0 1.00 8 46.4 4.80 30 86.0 7.00
-25 -13.0 1.50 9 48.2 4.90 31 87.8 7.10
-20 -4.0 2.00 10 50.0 5.00 32 89.6 7.20
-15 5.0 2.50 11 51.8 5.10 33 91.4 7.30
-10 14.0 3.00 12 53.6 5.20 34 93.2 7.40
-9 15.8 3.10 13 55.4 5.30 35 95.0 7.50
-8 17.6 3.20 14 57.2 5.40 36 96.8 7.60
-7 19.4 3.30 15 59.0 5.50 37 98.6 7.70
-6 21.2 3.40 16 60.8 5.60 38 100.4 7.80
-5 23.0 3.50 17 62.6 5.70 39 102.2 7.90
-4 24.8 3.60 18 64.4 5.80 40 104.0 8.00
-3 26.6 3.70 19 66.2 5.90 41 105.8 8.10
-2 28.4 3.80 20 68.0 6.00 42 107.6 8.20
-1 30.2 3.90 21 69.8 6.10 43 109.4 8.30
0 32.0 4.00 22 71.6 6.20 45 113.0 8.50
1 33.8 4.10 23 73.4 6.30 50 122.0 9.00
2 35.6 4.20 24 75.2 6.40 55 131.0 9.50
3 37.4 4.30 25 77.0 6.50 60 140.0 10.00
4 39.2 4.40 26 78.8 6.60
5 41.0 4.50 27 80.6 6.70
