45
SJ12 E, SJ16 E, SJ20 E
243762ABA
Function tests Section 4 – Inspections Before Operation
4.3-14 Do a test of the platform raise and
lower functions
WARNING
Look for overhead obstructions or other possible
hazards around the MEWP when you raise the
platform. Do not lower the platform unless the area
below is clear of personnel and obstructions. If
you do not obey, there is a risk of death or serious
injury.
1. Move the lift/off/drive switch
5
to the lift
position.
2. Squeeze and hold the function-enable switch
1
.
3. Push the controller handle
2
to raise the
platform by approximately 0.5 m (20 in).
▪
Result: The platform rises.
4. Squeeze and hold the function-enable switch
1
.
5. Pull the controller handle
2
to fully lower the
platform.
▪
Result: The platform fully lowers.
4.3-15 Do a test of the horn
1. Push the horn button
6
.
▪
Result: The horn makes a sound.
4.3-16 Do a test of the elevated travel
speed
WARNING
Look for overhead obstructions or other possible
hazards around the MEWP when you raise the
platform. Do not lower the platform unless the area
below is clear of personnel and obstructions. If
you do not obey, there is a risk of death or serious
injury.
1. Make sure the path of intended motion is clear.
2. Raise the platform approximately 1 m (3 ft 3 in)
from the ground.
3. Drive the MEWP forward and then rearward.
▪
Result: The MEWP drives slower than when it
was in the lowered travel position.
6 4
3
1
5
2
