31
SJ12 E, SJ16 E, SJ20 E
243762ABA
Optional equipment Section 3 – Familiarization
3.6-4 Wind rating control console
12
This function limits the height of the MEWP when
the wind speed is greater than 0 m/s (0 mph). Refer
to Section 5.4 for the operation of the wind rating
function.
1
Wind rating switch: This switch selects the indoor
(no wind) or the outdoor (wind) position.
2
Wind rating light
Wind rating light Status
On
The indoor (no wind) mode is
on. The platform can go to the
maximum height.
Off (SJ16 E)
The outdoor (wind) mode is
on. The platform can only go to
3.58 m (11 ft 9 in).
Off (SJ20 E)
The outdoor (wind) mode is
on. The platform can only go to
3.96 m (13 ft).
3.6-5 ECOTray leak containment system
The ECOTray system is designed to prevent any
potential leaks from the hydraulic system dripping on
internal components or the oor.
