SJ12 E, SJ16 E, SJ20 E243762ABA
Section 7 – Specications
Floor loading capacity
7.6 Floor loading capacity
Model
Total MEWP
weight
Total MEWP load
Wheel** LCP*** OFL***
SJ12 E
min* 913 kg (2012 lb) 295 kg (650 lb) 820 kPa (119 psi) 8.1 kPa (169 psf)
max* 1140 kg (2512 lb) 449 kg (990 lb) 1059 kPa (154 psi) 10.1 kPa (212 psf)
SJ16 E
min* 931 kg (2054 lb) 355 kg (783 lb) 910 kPa (132 psi) 8.4 kPa (175 psf)
max* 1158 kg (2554 lb) 510 kg (1125 lb) 1167 kPa (169 psi) 10.4 kPa (217 psf)
SJ20 E
min* 1107 kg (2440 lb) 276 kg (609 lb) 792 kPa (115 psi) 9.9 kPa (207 psf)
max* 1266 kg (2790 lb) 426 kg (940 lb) 1021 kPa (148 psi) 11.3 kPa (237 psf)
2164AA
*
Min: Minimum MEWP weight (unloaded platform, no options/attachments)
Max: Maximum MEWP weight (platform loaded to capacity with options or attachments)
**
Wheel is the weight that can be experienced on one wheel
Note: This is more than 25% of the machine weight due to possible weight distribution over the machine and
platform.
***
LCP: Local concentrated pressure is a measure of how hard the MEWP presses on the area in direct contact
with the  oor/tire.
OFL: Overall  oor load (Pressure) is a measure of the average load the MEWP imparts on the whole
surface directly underneath the chassis. This has been calculated by dividing the MEWP weight by the
overall  oor area occupied by the MEWP (on wheels).
Note: The  oor covering (e.g., tile, carpet, etc.) or the structure (e.g., beams) of the operating surface must
be able to withstand more than the values indicated above.
NOTE
The LCP or OFL that an individual surface can withstand varies from structure to structure and is
generally determined by the engineer or architect for that particular structure.
WARNING
Do not use tires other than the tires that Skyjack species for this MEWP. Do not mix different
types of tires or use tires that are not in good condition. Only replace the tires with the same
types that are approved by Skyjack. The use of other tires can make the MEWP less stable. If you
do not obey, there is a risk of death or serious injury.
