Specications Section 7 – Specications
Model SJ12 E SJ16 E SJ20 E
Weight * 913 kg (2012 Ib) 931 kg (2054 lb) 1107 kg (2440Ib)
Overall width 0.77 m (30.50 in) 0.77 m ( 30.5 in ) 0.80 m (31.5 in)
Overall length 1.37 m (54 in) 1.37 m ( 54 in ) 1.37 m (54 in)
Platform size (Inside)
0.69 m x 0.91 m
(27.13 in x 35.66 in)
0.69 m x 0.91 m
(27.13 in x 35.66 in)
0.69 m x 0.91 m
(27.13 in x 35.66 in)
Platform traversing 0.41 m (16.00 in) 0.41 m (16.00 in) 0.41 m (16 in)
Height
Working height 5.48 m (18 ft) 6.55 m (21 ft 6 in) 7.77 m (25 ft 6 in)
Platform elevated height 3.66 m (12 ft) 4.72 m (15 ft 6 in) 5.94 m (19 ft 6 in)
Stowed platform height (railings up) 1.88 m (74 in) 1.88 m (74 in) 2.01 m (79.19 in)
Drive height Full Full Full
Stowed platform height 0.75 m (29.7 in) 0.75 m (29.7 in) 0.75 m (29.7 in)
Standard operating times
Lift time (rated load) 15 s 21 s 26 s
Lower time (rated load) 16 s 22 s 26 s
Chassis
Stowed drive speed
Forward 3.5 km/h (2.2 mph) 3.5 km/h (2.2 mph) 3.0 km/h (1.9 mph)
Reverse 3.5 km/h (2.2 mph) 3.5 km/h (2.2 mph) 2.6 km/h (1.6 mph)
Elevated drive speed 0.5 km/h (0.3 mph) 0.5 km/h (0.3 mph) 0.5 km/h (0.3 mph)
Gradeability (ramp angle [reverse/forward])** 25% 25% 25%
Tires (solid rubber) 10 in x 4 in 10 in x 4 in 10 in x 4 in
Hydraulic oil
Type ATF Dexron III ATF Dexron III ATF Dexron III
Tank capacity 5.3 L (1.41 gal) 5.3 L (1.41 gal) 5.3 L (1.41 gal)
2162AB
7.3 Specications
* Weights are approximate; refer to the serial nameplate for the specic weight.
** Refer to Section 6.5: Move the MEWP for Transport in the operation manual for more details.
