79
SJ12 E, SJ16 E, SJ20 E
243762ABA
Front view Section 8 – Labels
Description Label Pictorial
5
Fall-protection anchorages
When required, attach the body-harness lanyards of each
occupant to the fall-protection anchorage points.
Rated for one (1) person for each anchorage point.
Note: This label is inside the platform above the fall-protection
anchorages.
TM
X1
6
Platform traversing procedure
Refer to the operation manual.
Follow this procedure to traverse the platform.
TM
7
Lift and tie-down points
Only use these points to lift or tie down the MEWP.
TM
8
No jewelry
Caution. Do not wear jewelry or loose clothing that could
become caught or entangled.
6
3
9
12
TM
9
Refer to the service manual
Remove the cover to perform the scheduled maintenance.
TM
Front view (continued)
SJ20E
5
6
7
8
9
