SLAYER STEAM LP USER MANUAL V1.1 | JUNE 2019 43
Parts Diagrams
Preventative Maintenance and appropriate water filtration will not only
extend the life of your espresso machine, it will additionally maintain the
output of high quality beverages. Only qualified service personnel should
repair Slayer Espresso machines. Incorrect repair may result in injury and/
or damage to the equipment. Please consult your distributor for a qualified
Slayer service technician.
CONTENTS
Brew Group Head Components 44
Brew Tank Assembly 46
Steam Tank Assembly 48
Steam & Hot Water Valve Train 50
Steam Wand Assembly 52
Hot Water Wand Assembly 54
Steam Actuator Assemblies 56
Water Fill Circuit 58
Drain Circuit 60
Display Assembly 62
Electronics Components 64
Panels, Rails & Wings 66
Drip Trays & Cup Trays 68
Pump Assembly & Lines 70
Portafilters 72
Wire Map 74
Incorrect repair may result in injury and/or damage to the equipment.
Please consult your distributor for a qualified Slayer service technician.
To Next Page
