SLAYER STEAM LP USER MANUAL V1.1 | JUNE 2019 45
BREW GROUP HEAD COMPONENTS
ITEM NO. PART NUMBER DESCRIPTION
1 44000-36152 SCREW,OVAL HD,1/4-20X0.50,SLOTTED,18-8 SS
2 44000-50210 INSERT NUT FOR BREW HANDLE, STAINLESS
3 44000-50190 SPACER FOR GROUP HANDLE
4 99015-10150 BREW ACTUATOR ASSEMBLY, ONYX DURATEX
5 44000-50260 GROUP COVER MOUNT SCREW
6 20000-16080 GROUP COVER
7 10000-16210 SPACER
8 44000-16220 WASHER, FENDER, 3/8 X 1.25 X 0.05, SS
9 99003-50051 TONGUE ASSY
10 44000-36130 SCREW/WASHER POWER SUPPLY
11 30000-20032 MAG SWITCH, N/C, PINNED
12 42000-34300 BLEED SCREW PLUG
13 46000-50270 STANDOFF, GROUP COVER
14 99004-16100 BREW CAP WITH MAGNET ASSY
15 46000-50100 GROUP CAP PAPER GASKET
16 46000-50090 GROUP CAP O RING
17 20000-56010 BAYONET RING
18 46000-50080 DIFFUSER SCREW, STAINLESS
19 46000-50073 NANO COATED SHOWER SCREEN
20 46000-56091 PORTAFILTER GASKET
21 44000-36000 INVERTED MAG SWITCH SPACER
22 30000-20042 MAG SWITCH, N/O, PINNED
23 44000-36140 SCREW/WASHER FOR INVERTED MAGNET
24 44000-56000 SCREW, SOCKET HEAD CAP, M8 THREAD, 55mm LENGTH, 1.25mm PITCH, STAINLESS
25 30005-20081 THERMISTOR, STEAM - 3K3 NTC
26 10000-16161 STEM, BREW ACTUATOR
27 46000-50240 DISC SPRING
28 10000-16200 OILITE BUSHING
29 46000-53070 TEFLON GASKET 27MM
