WIRE MAP: 3-GROUP MACHINES
GROUP 1 connection position wire color
GH1 SW-RIGHT CN14 2 YELLOW
1 BLACK/WHITE
GH1 SW-LEFT CN8 10 WHITE
RTD CN10 1 BLACK/WHITE
2 RED
LED CN19 2 BLACK/ORANGE
FLOW METER CN2 6 YELLOW/GREEN
BREW SOLENOID CN48 7 BLUE/WHITE
PRE-INF. SOLENOID CN48 1 WHITE / ORANGE
BREW HEATER CN18 2 GRAY
MANUAL MODE CN22 - GRAY / WHITE
GROUP 2 connection position wire color
GH2 SW-RIGHT CN17 2 YELLOW
1 BLACK/ MAROON
GH2 SW-LEFT CN8 16 ORANGE
RTD CN13 1 BLACK/BROWN
2 RED
LED CN21 2 BLACK/BLUE
FLOW METER CN2 7 YELLOW/ORANGE
BREW SOLENOID CN48 6 BLUE/BROWN
PRE-INF. SOLENOID CN48 4 WHITE / BLUE
BREW HEATER CN20 2 GRAY/YELLOW
MANUAL MODE CN23 - GRAY / BLUE
GROUP 3 connection position wire color
GH3 SW-RIGHT CN25 2 YELLOW
1 BLACK/ BLUE
GH3 SW-LEFT CN8 14 VIOLET / WHITE
RTD CN16 1 BLACK
2 RED
LED CN27 8 BLACK/WHITE
FLOW METER CN2 7 YELLOW/VIOLET
BREW SOLENOID CN48 5 BLUE/YELLOW
PRE-INF. SOLENOID MOD 3 1 WHITE / BLACK
BREW HEATER CN20 2 GRAY/ORANGE
MANUAL MODE CN23 - GRAY / BLACK
connection position wire color
GROUND CN2 1 GREEN
FLOW MTR GND CN2 2 BLACK
FLOW MTR +10Vdc CN2 3 RED
HOT WATER SW. CN11 2 VIOLET/BLACK
1 BLACK
STEAM SW. LEFT CN8 6 GREEN
STEAM SW. RIGHT CN8 2 GRAY
STEAM SOL.-LEFT MOD2 2 RED/WHITE
STEAM SOL. - RIGHT MOD1 2 ORANGE
LEVEL PROBE CN2 4 GRAY
AUTOFILL SOL. CN48 3 BROWN/WHITE
HOT WATER SOL. CN48 2 BROWN/YELLOW
STEAM HEATER CN28 2 BLACK/ORANGE
24vDC + CN1 1 RED
- CN1 3 BLACK
PUMP 115/240Vac CN49 4 WHITE
CN49 3 YELLOW
