Page 113 of 128
23.1 Electromagnetic immunity
Guidance and manufacturer's declaration - electromagnetic immunity
The SLE1000 is intended for use in the electromagnetic environment specified below. The customer or the user of the
SLE1000 should assure that it is used in such an environment.
Immunity test IEC 60601 test level Compliance level Electromagnetic
environment - guidance
Electrostatic discharge
(ESD)
IEC 61000-4-2
±6 kV Contact
±8 kV Air
±6 kV Contact
±8 kV Air
Floors should be wood,
concrete or ceramic tile. If
floors are covered with
synthetic material, the
relative humidity should be
at least 30 %.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for power supply
lines
±1 kV for input/output lines
±2 kV for power supply
lines
N/A
Mains power quality should
be that of a supply lines
typical commercial or
hospital environment.
Surge
IEC 61000-4-5
±1 kV line(s) to line(s)
±1 kV line(s) to earth
±1 kV line(s) to line(s)
±1 kV line(s) to earth
Mains power quality should
be that of a typical
commercial or hospital
environment. If the user of
the SLE1000 requires
continued operation during
power mains interruptions,
it is recommended that the
SLE1000 be powered from
an uninterruptible power
aupply or a battery.
Voltage dips, short
interruptions and voltage
variations on the power
supply input lines
IEC 61000-4-11
<5 % U
T
(>95% dip in U
T
) for 0.5
cycle
40 % U
T
(60% dip in U
T
) for 5 cycles
70 % U
T
(30% dip in U
T
) for 25
cycles
<5 % U
T
(>95% dip in U
T
) for 5 s
100% dip in U
T
for 0.01
seconds.
40 % U
T
(60% dip in U
T
) for 0.1
seconds.
70 % U
T
(30% dip in U
T
) for 0.5
seconds.
100% dip in U
T
for 5
seconds
Mains power quality should
be that of a typical
commercial or hospital
environment.
Power frequency (50/60
Hz) magnetic field
IEC 61000-4-8
3 A/m 3 A/m Power frequency magnetic
fields should be at levels
characteristic of a typical
location in a typical
commercial or hospital
environment.
NOTE U
T
is the a.c. mains voltage prior to application of the test level.
