14. SLE1000 Set-up
14.1 First use
Setting up the SLE1000 for the first time.
Step 1. Take the SLE1000 out of
its transport carton and
remove the protective
film.
Step 2. Remove the air and
oxygen inlet port caps.
Step 3. Check that the following
ports are free from any
packing material
A. Fresh gas port
B. Proximal pressure port
C. Air inlet
D. Oxygen inlet
E. Exhaust port


A
B
C


D

E
