Step 4. The SLE1000 is shipped
with the main battery
disconnected.
Using a screw driver
remove the battery fuse
holder. (Indicated by
arrow)
Step 5. Insert the fuse into the
fuse holder. (T2.0A
250V). (The fuse is
located in the accessory
pack, Part nº: M0457/
2AC/001)
Step 6. Insert the fuse holder and
fuse into the receptacle.
Do not over tighten.
Step 7. Remove the screw and
washer holding the P clip.
Insert the power cable
into the socket and secure
the cable with the P clip.
Allow 75mm of cable to
form the loop.
