CHAPTER 3
CONNECTING POWER AND DEVICES
14 smarttech.com/kb/170642
No. Type Details Identifier
Left connector panel
2 Audio out Stereo 3.5 mm connector
3
USB USB 2.0 Type-B receptacle
4 Video in HDMI connector HDMI
Back of the interactive flat panel
5 AC power AC power inlet and switch
NOTE
The HDMI cable should be HDMI 1.4 compliant and no longer than 16' 5" (5 m).
Connecting power
Connect the supplied power cable from the AC power inlet on the bottom of the interactive flat
panel to a power outlet. Turn on the main power switch.
NOTE
Refer to your interactive flat panel’s specifications for power requirements and power
consumption information (see Specifications on page7).
Connecting the computer
NOTES
l The interactive flat panel can be used with a maximum of two USB-XT extenders.
l If using a CAT 5 USB extender, the maximum length of Cat 5 cable is 52' (16 m).
