CHAPTER 6
MAINTAINING YOUR INTERACTIVEFLATPANEL
25 smarttech.com/kb/170642
To orient the interactive flat panel
1. Open SMARTSettings (see Opening SMARTSettings on page23).
2. Press Orient.
3. Press the red targets as they appear. Hold your finger or the tip of the pen at the center of
each target, and then lift the pen or finger. When you lift the pen or finger, the target moves to
the next orientation point.
IMPORTANT
Hold the pen perpendicular to the screen.
4. Continue until you’ve pressed all the targets.
The orientation window closes.
5. If this doesn’t correct inaccurate touch, calibrate your interactive flat panel (see Calibrating
your interactive flat panel below).
Calibrating your interactive flat panel
Digital cameras in the corners of the interactive flat panel track the position of the pens, eraser and
your finger on the interactive surface, and then send the information to the SMART software, which
interprets this information as mouse clicks, digital ink or ink removal in the appropriate location.
Calibration determines the position and angles of the cameras to accurately identify the location of
touches on your interactive flat panel.
IMPORTANT
If an error message appears while you are calibrating your interactive flat panel, contact
SMARTSupport (smarttech.com/contactsupport).
To calibrate your interactive flat panel
1. Open SMARTSettings (see Opening SMARTSettings on page23).
2. Press SMART Hardware Settings.
3. If you have more than one SMART product connected, select the interactive flat panel.
4. Select Advanced Settings from the drop-down list.
5. Press Calibrate.
The calibration screen appears. This can take a few moments.
