CHAPTER 6
MAINTAINING YOUR INTERACTIVEFLATPANEL
26 smarttech.com/kb/170642
6. Press the red target with the tip of an interactive flat panel pen. Hold the tip at the center of
the target until the target turns green, and then lift the pen.
The target moves to the next location.
NOTE
You can calibrate a target again by pressing the LEFT ARROW key on your keyboard.
7. Continue pressing targets until the second calibration screen and a grid appears.
An example appears briefly to demonstrate how to draw across the screen to calibrate the
interactive surface.
8. Use a pen to draw a spiral horizontally across the grid. As you draw, the ink is blue. As you
complete each square, the square becomes green.
9. When all the squares are green, a progress bar appears.
When the progress bar is full, the interactive flat panel displays the message Calibration
successful.
10. Orient your interactive flat panel (see Orienting your interactive flat panel on page24).
Replacing a pen nib
To prevent damage to your interactive flat panel’s anti-glare coating, replace your pen nib if it
becomes worn. You can purchase replacements from your authorized SMART reseller
(smarttech.com/where).
To replace a pen nib
1. Grasp the worn nib on your pen with a pair of pliers, and then pull and twist the nib loose.
2. Press the replacement nib into the pen.
Cleaning the screen
Follow these instructions to clean the interactive flat panel screen without damaging its anti-glare
coating or other product components.
CAUTION
l Do not use permanent or dry-erase markers on the screen. If dry-erase markers are used on
the screen, remove the ink as soon as possible with a lint-free, non-abrasive cloth.
l Do not rub the screen with a dense or rough material.
