SMART MX Series Installation And Maintenance Guide

Chapter 2
Installing the display
smarttech.com/kb/171555 29
TIP
If you’re using one of the display’s RJ45 jacks to connect to a network, you can connect a computer to the
other RJ45 jack to provide network access for the computer (pictured). This is particularly useful if there is
only one wired network connection in the room. (Network access is available when Networked Standby is
enabled in Settings but not when Standby is enabled in Settings.
SMARTBoard MX (V3) series SMARTBoard MX (V2 and V2-
C) series
SMARTBoard MX series
AM50 iQ appliance
For SMARTBoard MX series displays
There are three ways to connect the AM50 appliance included with the SBID-MX365, SBID-MX375, and
SBID-MX386 models to a network:
l
Wi-Fi
l
connect an Ethernet cable from a network outlet directly to the AM50 appliance’s RJ45 jack

SMART MX Series Specifications

General

Aspect Ratio	16:9
RAM	4 GB
Internal Storage	32 GB
Refresh Rate	60 Hz
Response Time	8 ms
Brightness	350 cd/m²
Contrast Ratio	4000:1
Dimensions (W x H x D)	Varies by screen size
Weight	Varies by screen size
Screen Sizes	65", 75", 86"
Operating System	Android
Connectivity	HDMI, USB, Wi-Fi, Bluetooth
Audio	Built-in speakers
Touch Points	20
Viewing Angle	178°
VESA Mount	Yes
Display Type	LED-backlit LCD
