SMART MX Series Installation And Maintenance Guide

Chapter 3
Connecting computers and other devices
smarttech.com/kb/171555 40
To view the input of a computer connected to a SMARTBoard MX series display
1. Connect the computer to the display.
2.
Press the Input on the front control panel.
The Input selection menu appears.
NOTE
Inputs with devices connected are blue, and inputs without a connection are black.
3. Tap the computer’s input menu option.
Setting a connected computer’s resolution and refresh rate
The following table presents the recommend resolutions and refresh rates for the display’s USB-C, HDMI1,
HDMI 2, and HDMI 3 input sources:
Resolution Input source
aspect ratio
Mode Refresh rate
3840 × 2160 16:9 UHD / 2160p 59.94 Hz / 60 Hz
50 Hz
29.97 Hz / 30 Hz
25 Hz
23.98 Hz / 24 Hz
1920 × 1080 16:9 FHD / 1080p 59.94 Hz / 60 Hz
50 Hz
29.97 Hz / 30 Hz
25 Hz
23.98 Hz / 24 Hz
1360 × 768 16:9 HD 60.015 Hz
1366 × 768 16:9 HD 60.015 Hz
1280 × 720 16:9 HD / 720p 59.94 Hz / 60 Hz
50 Hz
29.97 Hz / 30 Hz
25 Hz
23.98 Hz / 24 Hz
720 × 480 16:9 480p (DVD Player) 60 Hz

SMART MX Series Specifications

General

Aspect Ratio	16:9
RAM	4 GB
Internal Storage	32 GB
Refresh Rate	60 Hz
Response Time	8 ms
Brightness	350 cd/m²
Contrast Ratio	4000:1
Dimensions (W x H x D)	Varies by screen size
Weight	Varies by screen size
Screen Sizes	65", 75", 86"
Operating System	Android
Connectivity	HDMI, USB, Wi-Fi, Bluetooth
Audio	Built-in speakers
Touch Points	20
Viewing Angle	178°
VESA Mount	Yes
Display Type	LED-backlit LCD
