SMART MX Series Installation And Maintenance Guide

Appendix B
Adjusting display settings
smarttech.com/kb/171555 90
Option Values Function Notes
Wi-Fi hotspot
Wi-Fi hotspot
Enable
Disable
Enables or disables the Wi-Fi hotspot The lock screen appears after the
display wakes up from sleep.
Set up Wi-Fi hotspot
[N/A] Sets the network name, security,
password and access point frequency
Use the on-screen keyboard or
connect a USB keyboard to the
Display USB Type-A connector on the
front connector panel to enter
information.
Network status
[N/A] Shows information about the display’s
current network connection
[N/A]
Screen lock
Option Values Function Notes
Lock screen mode
Lock screen mode
Enable
Disable
Turns lock screen on or off [N/A]
[N/A] Select a custom image for the lock
screen
Supports .png, .jpg, .bmp files
Save the wallpaper file to a USBdrive
and insert it into the USB port. See
Connector diagrams on page46.
Disable
[N/A] Turns off the custom image for the
lock screen
[N/A]
Lock screen password
Enable
Disable
Set a PINto unlock the lock screen [N/A]
Settings security
Enable
Disable
Set a PIN to access certain settings When Settings security is enabled,
only Advanced and About settings are
available. To access the other
settings, tap the setting and enter the
PIN.

SMART MX Series Specifications

General

Aspect Ratio	16:9
RAM	4 GB
Internal Storage	32 GB
Refresh Rate	60 Hz
Response Time	8 ms
Brightness	350 cd/m²
Contrast Ratio	4000:1
Dimensions (W x H x D)	Varies by screen size
Weight	Varies by screen size
Screen Sizes	65", 75", 86"
Operating System	Android
Connectivity	HDMI, USB, Wi-Fi, Bluetooth
Audio	Built-in speakers
Touch Points	20
Viewing Angle	178°
VESA Mount	Yes
Display Type	LED-backlit LCD
