Smartgen HGM9510 User Manual

HGM9510 GENSET PARALLEL UNIT
HGM9510 Genset Parallel Unit ISSUE 2013-08-06 Version 1.1 Page 29 of 65
No.
Items
Parameters
Defaults
Description
of starter separation conditions and
inspecting of engine speed. See the
installation instructions.
3
Rated Speed
(0~6000)RPM
1500
Offer standard to judge
over/under/loading speed.
4
Loading Speed
(0~100)%
90
Setting value is percentage of rated
speed. Controller detects when it is
ready to load. It won’t switch on when
speed is under loading speed.
5
Loss of Speed
Signal
(0~3600)s
5
Time from detecting speed is 0 to
confirm the action.
6
Loss of Speed
Signal Action
(0~1)
0
0:Warn; 1:Shutdown
7
Over Speed
Shutdown
(0~200)%
114
Setting value is percentage of rated
speed and delay value (default: 2s) also
can be set.
8
Under Speed
Shutdown
(0~200)%
80
Setting value is percentage of rated
speed and delay value (default: 3s) also
can be set.
9
Over Speed Warn
(0~200)%
110
Setting value is percentage of rated
speed, delay value (default: 5s) and
return value (default: 108%) also can be
set.
10
Under Speed Warn
(0~200)%
86
Setting value is percentage of rated
speed, delay value (default: 5s) and
return value (default: 90%) also can be
set.
11
Battery Rated
Voltage
(0~60.0)V
24.0
Standard for detecting of over/under
voltage of battery.
12
Battery Over Volts
(0~200)%
120
Setting value is percentage of rated
voltage of battery, delay value (default:
60s) and return value (default: 115%)
also can be set.
13
Battery Under
Volts
(0~200)%
85
Setting value is percentage of rated
voltage of battery, delay value (default:
60s) and return value (default: 90%)
also can be set.
14
Charge Alt Fail
(0~60.0)V
8.0
In normal running, when charger
D+(WL) voltage under this value, charge
failure alarms. Delay value (default: 10s)
and return value (default: 10.0V) also
can be set.
15
Start Attempts
(1~10) times
3
Max. Crank times of crank attempts.
When reach this number, controller will
send start failure signal.
