Smartgen HGM9510 User Manual

HGM9510 GENSET PARALLEL UNIT
HGM9510 Genset Parallel Unit ISSUE 2013-08-06 Version 1.1 Page 30 of 65
No.
Items
Parameters
Defaults
Description
16
Crank Disconnect
(0~6)
2
See form 5
There are 3 conditions of disconnecting
starter with engine. Each condition can
be used alone and simultaneously to
separating the start motor and genset as
soon as possible.
17
Disconnect
Generator Freq
(0~200)%
30
When generator frequency higher than
the set value, starter will be
disconnected. See the installation
instruction.
18
Disconnect Engine
Speed
(0~200)%
30
When generator speed higher than the
set value, starter will be disconnected.
See the installation instruction.
19
Disconnect Oil
Pressure
(0~1000)kPa
200
When generator oil pressure higher than
the set value, starter will be
disconnected. See the installation
instruction.
Generator Setting
1
AC System
(0~3)
0
0: 3P4W; 1: 3P3W;
2: 2P3W; 3: 1P2W.
2
Poles
(2-32)
4
Numbers of generator pole, used for
calculating starter rotate speed when
without speed sensor.
3
Rated Voltage
(30~30000)V
230
To offer standards for detecting of gens’
over/under voltage and loading voltage.
(It is primary voltage when using voltage
transformer; it is line voltage when AC
system is 3P3W while it is phase voltage
when using other AC system).
4
Loading Voltage
(0~200)%
90
Setting value is percentage of generator
rated voltage. When gens voltage under
load voltage, won’t enter into normally
running, during the period of when
controller ready to detect loading.
5
Rated Frequency
(10.0-75.0)Hz
50.0
To offer standards for detecting of
over/under/load frequency.
6
Loading Frequency
(0~200)%
90
Setting value is percentage of generator
rated frequency. When generator
frequency under load frequency, it won’t
enter into normal running.
7
Volt. Trans.(PT)
(0~1)
0
0: Disable; 1:Enable
8
Over Volt.
Shutdown
(0~200)%
120
Setting value is percentage of generator
rated volt. Delay value (default: 3s) also
can be set.
9
Under Volt.
Shutdown
(0~200)%
80
Setting value is percentage of generator
rated volt. Delay value (default: 2s) also
