HGM9510 GENSET PARALLEL UNIT
HGM9510 Genset Parallel Unit ISSUE 2013-08-06 Version 1.1 Page 31 of 65
No.
Items
Parameters
Defaults
Description
can be set.
10
Over Freq.
Shutdown
(0~200)%
114
Setting value is percentage of generator
rated freq. Delay value (default: 2s) also
can be set.
11
Under Freq.
Shutdown
(0~200)%
80
Setting value is percentage of generator
rated freq. Delay value (default: 3s) also
can be set.
12
Over Volt. Warn
(0~200)%
110
Setting value is percentage of generator
rated volt. Delay value (default: 5s) and
return value (default: 108%) also can be
set.
13
Under Volt. Warn
(0~200)%
84
Setting value is percentage of generator
rated volt. Delay value (default: 5s) and
return value (default: 86%) also can be
set.
14
Over Freq. Warn
(0~200)%
110
Setting value is percentage of gens
rated freq. Delay value (default: 5s) and
return value (default: 108%) also can be
set.
15
Under Freq. Warn
(0~200)%
84
Setting value is percentage of gens
rated freq. Delay value (default: 5s) and
return value (default: 86%) also can be
set.
16
Loss of Phase
(0~1)
1
0: Disable 1: Enable
17
Phase Sequence
Wrong
(0~1)
1
Generator Load Setting
1
Current Trans.
(5~6000)/5
500
The ratio of external CT
2
Full Current Rating
(5~6000)A
500
Generator’s rated current, standard of
load current.
3
Full kW rating
(0-20000)kW
276
Generator’s rated power, standard of
load power.
4
Over Current
(0~200)%
120
Setting value is percentage of generator
rated volt. Delay value also can be set.
5
Over Power
(0~200)%
110
Setting value is percentage of generator
rated active power. Delay value (default:
30s) and action (default: trip and stop)
can be set.
6
Reverse Power
(0~200)%
10
Setting value is percentage of generator
rated active power. Delay value (default:
10s) and action (default: trip and stop)
can be set.
7
Earth Fault
(0~1)
0
0: Disable 1: Enable.
8
Negative
Sequence Current
(0~1)
0
0: Disable 1: Enable.
9
Loss of Excitation
(0~200)%
20
Setting value is percentage of generator
