Smartgen HGM9510 User Manual

HGM9510 GENSET PARALLEL UNIT
HGM9510 Genset Parallel Unit ISSUE 2013-08-06 Version 1.1 Page 32 of 65
No.
Items
Parameters
Defaults
Description
rated reactive power. Delay value
(default: 5s) and action (default: trip) can
be set.
Switch Setting
1
Close Time
(0~20.0)s
5.0
Pulse width of mains/generator switch
on. When it is 0, means output
constantly.
2
Open Time
(0~20.0)s
3.0
Pulse width of mains/ generator switch
off.
Module Setting
1
Power On Mode
(0~2)
0
0: Stop mode 1: Manual mode
2: Auto mode
2
Module Address
(1~254)
1
Controller’s address during remote
sensing.
3
Stop Bit
(0~1)
0
0: 2 stop bits; 1: 1 stop bit
4
Language
(0~2)
0
0: Simplified Chinese 1: English
2: Others
5
Password
(0~65535)
00318
For entering advanced parameters
setting.
6
Date and Time
Set the module’s date and time.
Scheduling And Maintenance Setting
1
Scheduled Run
(0~1)
0
0: Disable; 1: Enable
2
Scheduled Not
Run
(0~1)
0
0: Disable; 1: Enable
3
Maintenance
(0~1)
0
0: Disable; 1: Enable
Analog Sensors Setting
Temperature Sensor
1
Curve Type
(0~15)
7
SGX See form 4.
2
Open Circuit
Action
(0~2)
0
0: Warn 1: Shutdown
2: No action
3
High Temp.
Shutdown
(0-300)ºC
98
Shutdown when sensor temperature
higher than this value. Detecting only
after safety delay is over. The delay
value (default: 3s) also can be set.
4
High Temp Warn
(0-300)ºC
95
Warn when sensor temperature higher
than this value. Detecting only after
safety delay is over. The delay value
(default: 5s) and return value (default:
93) also can be set.
5
Low Temp. Warn
(0~1)
0
0: Disable; 1: Enable
Oil Pressure Sensor
1
Curve Type
(0~15)
7
SGX See form 4.
2
Open Circuit
Action
(0~2)
0
0: Warn 1: Shutdown 2: No action
3
Low OP Shutdown
(0~1000)kPa
103
Shutdown when oil pressure higher than
