HGMS62 Split Type Genset Controller User Manual Page 42 of 58
After input is active in auto mode, genset auto start is inhibited.
After input is active in auto mode, genset scheduled start is
inhibited.
Connect the auxiliary contactor of generator loading switch.
When input is active, genset will inhibit to close.
Connect the auxiliary contactor of mains loading switch.
When input is active, mains will inhibit to close.
When input is active, controller will enter into auto mode, and other
keys on the panel are inactive except for , and
displays on LCD status page.
When input is active, controller will not work in auto mode,
key is unavailable.
All shutdown alarms are inhibited except for emergency stop (also
called Battle Mode or Override Mode)
All outputs are inhibited in this mode.
When input is active, it means box temperature high warning alarm
is issued.
When input is active, controller will reset maintenance time and
date as pre-set values.
Connect to sensor digital input.
Connect to sensor digital input.
Connect to sensor digital input.
When input is active in auto mode, genset will start automatically,
and then genset takes on load after normal running. When input is
inactive, genset will stop automatically.
When input is active in auto mode, genset will start automatically
without taking load after normal running. When input is inactive,
genset will stop automatically.
When input is active in manual mode, genset will start
automatically. When input is inactive, genset will stop
automatically.
When engine type is 35 MTSC1 and is active, the target engine
speed increases 50RPM.
When engine type is 35 MTSC1 and is active, the target engine
speed decreases 50RPM.
When engine type is 35 MTSC1 and is active, the target engine
