HGMS62 Split Type Genset Controller User Manual Page 43 of 58
No.
Type
Function Description
speed goes to 750RPM.
43
Reserved
44
Reserved
45
Simulate Mains OK
In auto mode if input is active, then mains is OK.
46
Simulate Mains Failure
In auto mode if input is active, then mains is abnormal.
47
Alternative Config 1
Active
When input port is active, alternative configuration is available.
Alternative configuration can be set as different parameters, which
is convenient to select current configuration via input ports.
48
Alternative Config 2
Active
49
Alternative Config 3
Active
50
Reserved
8.4 SENSOR SELECTION
Table 16 – Sensor Selection
No.
Items
Content
Description
1
Temperature
Sensor
0 Not used
1 Use-defined Resistance Curve
2 User-defined Current/Voltage Curve
3 VDO
4 CURTIS
5 VOLVO-EC
6 DATCON
7 SGX
8 SGD
9 SGH
10 PT100
11 SUZUKI
12-14 Reserved
15 Digital Input Port 5
Defined input resistance range is
0Ω~6000Ω, factory default is
SGD sensor.
2
Oil Pressure
(Pressure) Sensor
0 Not used
1 Use-defined Resistance Curve
2 User-defined Current/Voltage Curve
3 VDO
4 CURTIS
5 VOLVO-EC
6 DATCON
7 SGX
8 SGD
9 SGH
10 PT100
11 SUZUKI
Defined input resistance range is
0Ω~6000Ω, factory default is
SGD sensor.
