HGMS62 Split Type Genset Controller User Manual Page 36 of 58
8.2 DEFINED CONTENTS OF AUXILARY OUTPUT 1-4
8.2.1 DEFINED CONTENTS TABLE OF AUXILARY OUTPUT 1-4
Table 14 – Defined Contents of Auxiliary Output 1-4
No.
Type
Function Description
0
Not Used
1
Custom Period Output 1
Function description refers to the following contents.
2
Custom Period Output 2
3
Custom Period Output 3
4
Custom Period Output 4
5
Custom Period Output 5
6
Custom Period Output 6
7
Custom Combination
Output 1
8
Custom Combination
Output 2
9
Custom Combination
Output 3
10
Custom Combination
Output 4
11
Custom Combination
Output 5
12
Custom Combination
Output 6
13
Reserved
14
Reserved
15
Reserved
16
Reserved
17
Air Flap Control
Action in over speed shutdown and emergency shutdown, it can
close engine inlet port.
18
Audible Alarm
Action in warning, shutdown, ELE trip. It can connect an alarm
externally. When “Alarm Mute” is active, its output is inhibited.
19
Louver Control
Action in genset starts, it disconnects after genset stops
completely.
20
Fuel Pump Control
Its action is controlled by fuel pump threshold of level sensor.
21
Heater Control
Its action is controlled by heating control threshold of temp
sensor.
22
Cooler Control
Its action is controlled by cooling control threshold of temp
sensor.
23
Pre-fuel Output
Action in crank-safety running.
24
Excitation Output
Outputs in crank process, if there is no gen frequency in high
speed running, it outputs 2s again.
