HGMS62 Split Type Genset Controller User Manual Page 55 of 58
14.11 MTU ADEC (SMART MODULE)
It is suitable for MTU engine with ADEC (ECU8) and SMART module.
Table 34 – ADEC (X1 Port)
Terminals of controller
ADEC (X1 port)
Remark
Fuel relay output
X1 10
X1 Terminal 9 connected to battery
negative.
Crank relay output
X1 34
X1 Terminal 33 connected to battery
negative.
Table 35 – SMART (X4 Port)
Terminals of controller
SMART (X4 port)
Remark
CAN(H)
X4 1
Using impedance 120Ω connecting line.
CAN(L)
X4 2
Using impedance 120Ω connecting line.
Engine type: MTU-ADEC.
14.12 MTU ADEC (SAM MODULE)
It is suitable for MTU engine with ADEC (ECU7) and SAM module.
Table 36 – ADEC (X1 Port)
Terminals of controller
ADEC (X1 port)
Remark
Fuel relay output
X1 43
X1 Terminal 28 connected to battery
negative .
Crank relay output
X1 37
X1 Terminal 22 connected to battery
negative.
Table 37 – SAM (X23 Port)
Terminals of controller
SAM (X23 port)
Remark
CAN(H)
X23 2
Using impedance 120Ω connecting line.
CAN(L)
X23 1
Using impedance 120Ω connecting line.
Engine type: Common J1939.
14.13 PERKINS
It is suitable for ADEM3/ADEM4 engine control module. Engine type is 2306, 2506, 1106, and 2806.
Table 38 – Connector
Terminals of controller
Connector
Remark
Fuel relay output
1, 10, 15, 33, 34
Crank relay output
-
Connect to starter coil directly.
CAN(H)
31
Using impedance 120Ω connecting line.
CAN(L)
32
Using impedance 120Ω connecting line.
Engine type: PERKINS.
