HGMS62 Split Type Genset Controller User Manual Page 53 of 58
14.4 CUMMINS QSX15-CM570
It is suitable for CM570 engine control module. Engine type is QSX15.
Table 25 – 50 Pins Connector
Terminals of controller
50 pins connector
Remark
Fuel relay output
38
Oil spout switch.
Crank relay output
-
Connect to starter coil directly.
Table 26 – 9 Pins Connector
Terminals of controller
9 pins connector
Remark
CAN(H)
SAE J1939 signal-C
Using impedance 120Ω connecting line.
CAN(L)
SAE J1939 return-D
Using impedance 120Ω connecting line.
Engine type: CUMMINS -CM570.
14.5 CUMMINS GCS-MODBUS
It is suitable for GCS engine control module. Using RS485-MODBUS to read information of engine.
Engine types are QSX15, QST30, QSK23/45/60/78 and so on.
Table 27 – D-SUB Connector 06
Terminals of controller
D-SUB connector 06
Remark
Fuel relay output
5&8
Outside expand relay, when fuel outputs,
connect Port 05 and Port 08 of the
Connector 06.
Crank relay output
-
Connect to starter coil directly.
Table 28 – D-SUB Connector 06
Terminals of controller
D-SUB connector 06
Remark
RS485+
21
Using impedance 120Ω connecting line.
RS485-
18
Using impedance 120Ω connecting line.
Engine type: CUMMINS-QSK-Modbus, CUMMINS -QST- MODBUS, CUMMINS-QSX-MODBUS.
14.6 CUMMINS QSM11
Table 29 – Engine OEM Connector
Terminals of controller
Engine OEM connector
Remark
Fuel relay output
38
Crank relay output
-
Connect to starter coil directly.
CAN(H)
46
Using impedance 120Ω connecting line.
CAN(L)
37
Using impedance 120Ω connecting line.
Engine type: common J1939.
