HGMS62 Split Type Genset Controller User Manual Page 56 of 58
14.14 SCANIA
It is suitable for S6 engine control module. Engine type is DC9, DC12, and DC16.
Table 39 B1 Connector
Terminals of controller
B1 connector
Remark
Fuel relay output
3
Set aux. output 1 as “Fuel Output”.
Crank relay output
-
Connect to starter coil directly.
CAN(H)
9
Using impedance 120Ω connecting line.
CAN(L)
10
Using impedance 120Ω connecting line.
Engine type: SCANIA.
14.15 VOLVO EDC3
Suitable engine control model is TAD1240, TAD1241, and TAD1242.
Table 40 “Stand aloneConnector
Terminals of controller
“Stand alone” connector
Remark
Fuel relay output
H
Crank relay output
E
Aux. output 2
P
Set aux. output 2 as ECU Power.
Table 41 “Data bus” Connector
Terminals of controller
“Data bus” connector
Remark
CAN(H)
1
Using impedance 120Ω connecting line.
CAN(L)
2
Using impedance 120Ω connecting line.
Engine type: VOLVO.
NOTE: When this engine type is selected, preheating time should be set to at least 3 seconds.
14.16 VOLVO EDC4
Suitable engine types are TD520, TAD520 (optional), TD720, TAD720 (optional), TAD721, TAD722, and
TAD732.
Table 42 Connector
Terminals of controller
Connector
Remark
Fuel relay output
Expanded 30A relay, and
relay offers battery voltage
to Terminal 14. Fuse is
16A.
Crank relay output
-
Connect to starter coil directly.
1
Connected to battery negative.
CAN(H)
12
Using impedance 120Ω connecting line.
CAN(L)
13
Using impedance 120Ω connecting line.
Engine type: VOLVO-EDC4.
