HGMS62 Split Type Genset Controller User Manual Page 54 of 58
14.7 CUMMINS QSZ13
Table 30 – Engine OEM Connector
Terminals of controller
Engine OEM connector
Remark
Fuel relay output
45
Crank relay output
-
Connect to starter coil directly.
CAN(H)
1
Using impedance 120Ω connecting line.
CAN(L)
21
Using impedance 120Ω connecting line.
Engine type: Common J1939.
14.8 DETROIT DIESEL DDEC III / IV
Table 31 – Engine CAN Port
Terminals of controller
Engine CAN port
Remark
Fuel relay output
Expand 30A relay, ECU
battery voltage is supplied
by relay.
Crank relay output
-
Connect to starter coil directly.
CAN(H)
CAN(H)
Using impedance 120Ω connecting line.
CAN(L)
CAN(L)
Using impedance 120Ω connecting line.
Engine type: Common J1939.
14.9 DEUTZ EMR2
Table 32 – F Connector
Terminals of controller
F connector
Remark
Fuel relay output
Expand 30A relay, battery
voltage of 14 is supplied by
relay. Fuse is 16A.
Crank relay output
-
Connect to starter coil directly.
-
1
Connect to battery negative.
CAN(H)
12
Using impedance 120Ω connecting line.
CAN(L)
13
Using impedance 120Ω connecting line.
Engine type: VOLVO- EDC4.
14.10 JOHN DEERE
Table 33 – 21 Pins Connector
Terminals of controller
21 pins connector
Remark
Fuel relay output
G, J
Crank relay output
D
CAN(H)
V
Using impedance 120Ω connecting line.
CAN(L)
U
Using impedance 120Ω connecting line.
Engine type: JOHN DEERE.
