HGMS62 Split Type Genset Controller User Manual Page 41 of 58
S1 or S2 is TRUE, while S3 is TRUE, custom combination output is outputting;
S1 and S2 are FALSE, or S3 is FALSE, custom combination output is not outputting.
NOTE1: S1, S2, S3 can be set as any contents except for “custom combination output” itself in the output setting.
NOTE2: 3 parts of custom combination output (S1, S2, S3) couldn’t include or recursively include themselves.
For example:
Contents of or condition output S1: input port 1 is active;
Close when or condition output S1 is active /inactive: close when active (disconnect when inactive);
Contents of or condition output S2, input port 2 is active;
Close when or condition output S2 is active /inactive: close when active (disconnect when inactive);
Contents of and condition output S3: input port 3 is active;
Close when and condition output S3 is active /inactive: close when active (disconnect when inactive);
When input port 1 active or input port 2 active, if input port 3 is active, custom combination output is outputting; If input
port 3 inactive, custom combination output is not outputting;
When input port 1 inactive and input port 2 inactive, whatever input port 3 is active or not, customc combination
output is not outputting
8.3 DEFINED CONTENTS OF DIGITAL INPUT 1-9
Table 15 – Defined Contents of Digital Input 1-9 (All GND (B-) Active)
No.
Type
Function Description
0
User-defined
Users can define contents as bellow:
Indication: only display without warning and shutdown.
Warning: only warning without shutdown.
Shutdown: alarm and shutdown immediately.
Trip and stop: alarm, generator ramp-off load and stop after
high-speed cooling.
Trip: alarm, generator ramp-off load but not stop.
Inactive: input doesn’t work.
Always active: input detects all the time.
Active from crank: start detecting at the beginning of startup.
Active after safety delay: detecting after safety on delay is expired.
1
Reserved
2
Alarm Mute
“Audible Alarm” in output configuration outputs when it is active.
3
Alarm Reset
Shutdown alarm, trip alarm can be reset when it is active.
4
60Hz Active
Used for ECU engine with CANBUS, and it is 60Hz when active.
5
Lamp Test
When input is active, all LED indicators are light.
6
Panel Lock
When input is active, other keys on the panel are inactive except
for , and displays on LCD status page.
7
Reserved
8
Idle Mode
Under speed, under frequency and under voltage are not protected
in this mode.
9
Inhibit Auto Stop
After generator is normal running in auto mode, when input is
active, genset auto stop function is inhibited.
