HGMS62 Split Type Genset Controller User Manual Page 8 of 58
3 SPECIFICATION
Table 3 – Performance Parameters
Item
Content
Working Voltage
Range: DC8V~DC35V, continuous power supply, DC reverse connection
protection
Resolution: 0.1V
Accuracy: 1%
Overall Consumption
<9W (standby mode≤2.5W)
AC Voltage
3P4W: 15V AC - 360V AC (ph-N)
3P3W: 30V AC - 620V AC (ph-ph)
1P2W: 15V AC - 360V AC (ph-N)
2P3W: 15V AC - 360V AC (ph-N)
Resolution: 1V
Accuracy: 1%
AC Frequency
Range: 10Hz-75Hz
Resolution: 0. 1Hz
Accuracy: 0.1Hz
AC Current
Rated: 5A
Range: 0A - 10A
Resolution: 0.1A
Accuracy: 1%
Speed Sensor
Voltage Range: 1V - 24V (RMS)
Frequency Range: 5Hz - 10000Hz
Charger (D+) Voltage
Range: DC0V - DC60V continuous power supply
Resolution: 0.1V
Accuracy: 1%
Analog Sensor
Resistance Input
Range: 0Ω - 6000Ω
Resolution: 0.1Ω
Accuracy: 1Ω (below 300Ω)
Voltage Input
Range: 0V - 5V
Resolution: 0.1V
Accuracy: 0.1V
Current Input
Range: 4mA-20mA
Resolution: 0.01mA
Accuracy: 0.2mA
Fuel Relay Output
10A DC24V supply output (relay output, pluggable)
Crank Relay Output
10A DC24V supply output (relay output, pluggable)
Digital Output 1
7A DC24V supply output (relay output)
Digital Output 2
7A AC250V volts free output (relay output)
