HGMS62 Split Type Genset Controller User Manual Page 9 of 58
Item
Content
Digital Output 3
10A AC250V volts free output (relay output, pluggable)
Digital Output 4
10A AC250V volts free output (relay output, pluggable)
Overall Dimensions
HGMS62D: 209*167*45mm
HGMS62M: 243*158*65mm
Panel Cutout
HGMS62D: 186*141mm
HGMS62M: hole space: 230.5*125.5mm; aperture: Φ5.5
CT Secondary Current
Rated: 5A
Working Temperature
(-25~+70)°C
Working Humidity
(20~93)%
Storage Temperature
(-30~+80)°C
Protection Level
HGMS62D: IP65 HGMS62M: IP20
Insulation Strength
Apply AC2.2kV voltage between high voltage terminal and low voltage
terminal. The leakage current is not more than 3mA within 1min.
Weight
HGMS62D: 0.5kg
HGMS62M: 1.0kg
