HGMS62 Split Type Genset Controller User Manual Page 37 of 58
No.
Type
Function Description
25
Oil Pre-lubricate Output
Action in preheat-safety running.
26
Remote Comm. Control
It is controlled by PC.
27
Reserved
28
Reserved
29
Gen Closed Output
Can control gen breaker close.
30
Open Output
Can control breaker open.
31
Mains Closed Output
Can control mains breaker close.
32
Reserved
33
Crank Relay Output
Outputs in crank delay process, disconnect after crank success.
34
Fuel Relay Output
Action in genset start, disconnect In ETS.
35
Idle Control
Used for machines with idle, pick up before cranking, disconnect
after entering warming up, pick up in stop idle process and
disconnect after stopping completely.
36
Raise Speed Output
Action in high speed warming up.
37
Drop Speed Output
Action in stop idle-wait for stop.
38
ETS Control
Used for oil engine with stop solenoid, pick up when stop idle is
over. It will disconnect when set “ETS Delay” is over.
39
Pulse Drop Speed
Output
Action when entering stop idle, the action continue time is drop
speed pulse output time.
40
ECU Stop
Suitable for engine supports ECU, used for control ECU stop.
41
ECU Power
Suitable for engine supports ECU, used for control ECU power.
42
Pulse Raise Speed
Output
Action after entering high speed warming up, the action continue
time is raise speed pulse output time.
43
Crank Success
Pick up when detecting crank success signal.
44
Gen Normal
Action in gen normal.
45
Gen Available
Action in gen normal running and high speed cooling.
46
Mains Normal
Action in mains normal.
47
Full Speed Output
Action when engine speed is higher than loading speed.
48
Common Alarm
Action when common warning, common shutdown and common
ELE trip occur.
49
Common Trip and Stop
Action when common trip and stop alarm occurs.
50
Common Shutdown
Action when common shutdown alarm occurs.
51
Common Trip
Action when common trip alarm occurs.
52
Common Warning
Action when common warning alarm occurs.
53
Reserved
54
Battery Over High Volt
Action when battery over high warning alarm occurs.
55
Battery Over Low Volt
Action when battery over low warning alarm occurs.
56
Charge Failure
Action when charging genset failure warning occurs.
57
Reserved
58
Reserved
59
ECU Key Switch
Action after fuel outputs 3s, stops after ETS.
60
ECU Warning Alarm
Indicate that ECU sends a warning alarm signal.
