HGMS62 Split Type Genset Controller User Manual Page 35 of 58
No.
Items
Range
Default
Description
1
Content Set
(0-50)
27
Low oil pressure shutdown input. See
Table 15.
2
Active Type
(0-1)
0
0: Close; 1: Open.
Input Port 4 Setting
1
Content Set
(0-50)
0
User-defined. See Table 15.
2
Active Type
(0-1)
0
0: Close; 1: Open.
3
Active Range
(0-3)
2
0: After Safety Delay; 1: From Start; 2:
Always; 3: Inactive.
4
Active Action
(0-4)
0
0: Warning; 1: Shutdown; 2: Trip and
Stop; 3: Trip; 4: Indication.
5
Active Delay
(0-20.0)s
2.0
Time from detecting input port is active
to confirm.
6
Input Port Description
When the input port is active, it is the
LCD display content.
Input Port 5 Setting
Same as setting of input port 4.
Input Port 6 Setting
Input Port 7 Setting
Input Port 8 Setting
Input Port 9 Setting
Relay Output Setting
Output Port 1 Setting
1
Content Set
(0-239)
1
Custom period output 1 (default as
output in preheat). See Table 14.
2
Output Type
(0-1)
0
0: Normally Open; 1: Normally Close.
Output Port 2 Setting
1
Content Set
(0-239)
35
Idle control. See Table 14.
2
Output Type
(0-1)
0
0: Normally Open; 1: Normally Close.
Output Port 3 Setting
1
Content Set
(0-239)
29
Gen closed output. See Table 14.
2
Output Type
(0-1)
0
0: Normally Open; 1: Normally Close.
Output Port 4 Setting
1
Content Set
(0-239)
31
Mains closed output. See Table 14.
2
Output Type
(0-1)
0
0: Normally Open; 1: Normally Close.
