Table 10-7 Byte 0 Safe power supply for Safety Mode (Module Passivation/xxx) (outputs)
Bit
Description
Explanation
0
Safe power supply of US2 to the IO modules
0: OFF, 1: ON
1
Safe power supply of US2 to the valve zone 1
0: OFF, 1: ON
2
Safe power supply of US2 to the valve zone 2
0: OFF, 1: ON
3
Safe power supply of US2 to the valve zone 3
0: OFF, 1: ON
4…7
Reserved
Fixed 0
Table 10-8 Byte1 Output feedback parameter for zone M for Safety Mode (Module Passivation/xxx)
Bit 2
Bit 1
Bit 0
Value for OFF feedback delay time for Zone M
0
0
0
Reserved
0
0
1
Reserved
0
1
0
Reserved
0
1
1
5 sec
1
0
0
1 sec
1
0
1
500 msec
1
1
0
200 msec
1
1
1
100 msec
Bit 5
Bit 4
Bit 3
Value for ON feedback delay time for Zone M
0
0
0
Reserved
0
0
1
Reserved
0
1
0
Reserved
0
1
1
5 sec
1
0
0
1 sec
1
0
1
500 msec
1
1
0
200 msec
1
1
1
100 msec
Bit 6
Output feedback for Zone M
0
Disable
1
Enable
Bit 7
Reserved
