Table 10-9 Byte2 Output feedback parameter zone 1 for Safety Mode (Module Passivation/xxx)
Bit 2
Bit 1
Bit 0
Value for OFF feedback delay time for zone 1
Same as Table 10-8
Bit 5
Bit 4
Bit 3
Value for ON feedback delay time for zone 1
Same as Table 10-8
Bit 6
Output feedback for Zone 1
0
Disable
1
Enable
Bit 7
Reserved
Table 10-10 Byte3 Output feedback parameter zone 2 and zone 3 for Safety Mode (Module Passivation/xxx)
Bit 2
Bit 1
Bit 0
Value for OFF feedback delay time for zone 2 and zone 3
Same as Table 10-8
Bit 5
Bit 4
Bit 3
Value for ON feedback delay time for zone 2 and zone 3
Same as Table 10-8
Bit 6
Output feedback for Zone 2
0
Disable
1
Enable
Bit 7
Output feedback for Zone 3
0
Disable
1
Enable
