- 57 -
No.EX##-OMY0004
Table 10-11 Byte4 Safe input parameter for Ch.0 and Ch.4 (input connector 0) for Safety Mode (Module
Passivation/xxx)
Bit 1
Bit 0
Sensor evaluation for Ch.0 and Ch.4 (input connector 0)
0
0
Disable
0
1
1 out of 1 evaluation (Input 0, 4) *
1
0
1 out of 2 evaluation, 2-channel equivalent
1
1
1 out of 2 evaluation, 2-channel non-equivalent
Bit 3
Bit 2
Power source for cross circuit detection and Clock pulse for Ch.0 and Ch.4 (input
connector 0)
0
0
Input 0 power source: UT1 with clock pulse
Input 4 power source: UT2 with clock pulse
0
1
Input 0 & 4 power source: UT1 with clock pulse
1
0
Input 0 & 4 power source: UT2 with clock pulse
1
1
Input 0 & 4 power source: each power source without clock pulse
Bit 6
Bit 5
Bit 4
Discrepancy time for Ch.0 and Ch.4 (input connector 0)
0
0
0
Reserved
0
0
1
No limit (Disable)
0
1
0
10 msec
0
1
1
50 msec
1
0
0
100 msec
1
0
1
1 sec
1
1
0
5 sec
1
1
1
Reserved
Bit 7
Input filter time for Ch.0 and Ch.4 (input connector 0)
0
3 msec
1
5 msec
* When using 1oo1, please set “No limit (Disable)” for Discrepancy time in Ch.n and Ch.n+4.
Table 10-12 Byte5 Safe input parameter for Ch.1 and Ch.5 (input connector 1) for Safety Mode (Module
Passivation/xxx)
Bit 1
Bit 0
Sensor evaluation for Ch.1 and Ch.5 (input connector 1)
0
0
Disable
0
1
1 out of 1 evaluation (Input 1, 5)
1
0
1 out of 2 evaluation, 2-channel equivalent
1
1
1 out of 2 evaluation, 2-channel non-equivalent
Bit 3
Bit 2
Power source for cross circuit detection and Clock pulse for Ch.1 and Ch.5 (input
connector 1)
0
0
Input 1 power source: UT1 with clock pulse
Input 5 power source: UT2 with clock pulse
0
1
Input 1 & 5 power source: UT1 with clock pulse
1
0
Input 1 & 5 power source: UT2 with clock pulse
1
1
Input 1 & 5 power source: each power source without clock pulse
Bit 6
Bit 5
Bit 4
Discrepancy time for Ch.1 and Ch.5 (input connector 1)
Same as Table 10-11
Bit 7
Input filter time for Ch.1 and Ch.5 (input connector 1)
Same as Table 10-11
