SMC Networks EX245-FPS1 User Manual

- 58 -
No.EX##-OMY0004
Table 10-13 Byte6 Safe input parameter for Ch.2 and Ch.6 (input connector 2) for Safety Mode (Module
Passivation/xxx)
Bit 1
Bit 0
Sensor evaluation for Ch.2 and Ch.6 (input connector 2)
0
0
Disable
0
1
1 out of 1 evaluation (Input 2, 6)
1
0
1 out of 2 evaluation, 2-channel equivalent
1
1
1 out of 2 evaluation, 2-channel non-equivalent
Bit 3
Bit 2
Power source for cross circuit detection and Clock pulse for Ch.2 and Ch.6 (input
connector 2)
0
0
Input 2 power source: UT1 with clock pulse
Input 6 power source: UT2 with clock pulse
0
1
Input 2 & 6 power source: UT1 with clock pulse
1
0
Input 2 & 6 power source: UT2 with clock pulse
1
1
Input 2 & 6 power source: each power source without clock pulse
Bit 6
Bit 5
Bit 4
Discrepancy time for Ch.2 and Ch.6 (input connector 2)
Same as Table 10-11
Bit 7
Input filter time for Ch.2 and Ch.6 (input connector 2)
Same as Table 10-11
Table 10-14 Byte7 Safe input parameter for Ch.3 and Ch.6 (input connector 3) for Safety Mode (Module
Passivation/xxx)
Bit 1
Bit 0
Sensor evaluation for Ch.3 and Ch.7 (input connector 3)
0
0
Disable
0
1
1 out of 1 evaluation (Input 3, 7)
1
0
1 out of 2 evaluation, 2-channel equivalent
1
1
1 out of 2 evaluation, 2-channel non-equivalent
Bit 3
Bit 2
Power source for cross circuit detection and Clock pulse for Ch.3 and Ch.7 (input
connector 3)
0
0
Input 3 power source: UT1 with clock pulse
Input 7 power source: UT2 with clock pulse
0
1
Input 3 & 7 power source: UT1 with clock pulse
1
0
Input 3 & 7 power source: UT2 with clock pulse
1
1
Input 3 & 7 power source: each power source without clock pulse
Bit 6
Bit 5
Bit 4
Discrepancy time for Ch.3 and Ch.7 (input connector 3)
Same as Table 10-11
Bit 7
Input filter time for Ch.3 and Ch.7 (input connector 3)
Same as Table 10-11
