(700) Valve opening
characteristic setting
Valve opening characteristic can be set. The characteristic is
plotted by 11 points as specified by user.
Hold down the set button ( )
for 1sec. or longer to start
parameter change mode.
Select from the following by Down
or Up button ( ).
- Linear (Lin)
- Equal percent 25 (EP25)
- Equal percent 50 (EP50)
- Quick opening 25 (qO25)
- Quick opening 50 (qO50)
- User (USEr)
When selecting other than user
(USEr), hold down mode button
( ) for 1sec. or longer to select. To
select user (USEr), hold down set
button ( ) for 1sec. or longer
to start value change mode.
<Hereafter, only when user (USEr) is selected>
For user specification setting, hold
down the set button ( ) with
input current parameter for 1sec. or
longer. After values start flashing,
change the value within the range
of -20 to 120.0%. After changing,
hold down mode button ( ) for
1sec. or longer to set the value.
