C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 37 –
Port Security
Switch Shows information about MAC address learning for each
port, including the software module requesting port security
services, the service state, the current number of learned
addresses, and the maximum number of secure addresses
allowed
211
Port Shows the entries authorized by port security services,
including MAC address, VLAN ID, the service state, time
added to table, age, and hold state
213
NAS Shows global and port settings for IEEE 802.1X
Switch Shows port status for authentication services, including
802.1X security state, last source address used for
authentication, and last ID
214
Port Displays authentication statistics for the selected port –
either for 802.1X protocol or for the remote authentication
server depending on the authentication method
215
ACL Status Shows the status for different security modules which use
ACL filtering, including ingress port, frame type, and
forwarding action
219
DHCP Dynamic Host Configuration Protocol
Snooping
Statistics
Shows statistics for various types of DHCP protocol packets 221
Relay
Statistics
Displays server and client statistics for packets affected by
the relay information policy
222
ARP Inspection Displays entries in the ARP inspection table, sorted first by
port, then VLAN ID, MAC address, and finally IP address
223
IP Source Guard Displays entries in the IP Source Guard table, sorted first by
port, then VLAN ID, MAC address, and finally IP address
224
AAA Authentication, Authorization and Accounting 225
RADIUS
Overview
Displays status of configured RADIUS authentication and
accounting servers
225
RADIUS Details Displays the traffic and status associated with each
configured RADIUS server
226
LACP Link Aggregation Control Protocol 229
System Status Displays administration key and associated local ports for
each partner
229
Port Status Displays administration key, LAG ID, partner ID, and partner
ports for each local port
230
Port Statistics Displays statistics for LACP protocol messages 231
Spanning Tree 232
Bridge Status Displays global bridge and port settings for STA 232
Port Status Displays STA role, state, and uptime for each port 234
Port Statistics Displays statistics for RSTP, STP and TCN protocol packets 235
MVR Multicast VLAN Registration 236
Statistics Shows statistics for IGMP protocol messages used by MVR 236
Group Information Shows information about the interfaces associated with
multicast groups assigned to the MVR VLAN
237
Table 4: Main Menu (Continued)
Menu Description Page
