BTP-2002NP User’s Manual
2.2 Cutter Specification
Item Parameter Remarks
Cutter type Slide cutter (Guillotine type)
Cutting time 600ms The time that one cut takes.
Cutting interval 2s 30 times/min. (Max.)
Paper type Thickness: 0.065 – 0.1mm Thermal paper or paper with the same thickness
Operation voltage 24VDC
Max. static current 1.2A 24V DC
Cutter lifetime 1,500,000 cuts Full cut or Partial cut
2.3 Electric Parameters of the Power Supply
Supply voltage: 24VDC±5%
Current consumption:
Mean: approximately 2.5A (12.5% duty ratio)
Peak: Approximately 8 A
Ripple & Noise: < 240mVp-p
Caution:
Please use the power supply that is supplied with the printer or an equivalent type.
2.4 Paper Specification
¾ Paper type: thermal paper
¾ Paper width： 82.5±0.5mm, 80±0.5 mm, 76±0.5 mm, 69.5±0.5 mm
57.5±0.5 mm
¾ Paper thickness： 0.065 – 0.1mm
¾ Paper roll O/D： Max. 83 mm
¾ Printing surface: Outside of roll paper
¾ Recommend paper： POS-grade paper with a thickness of 0.065 – 0.1mm
(Reference: Mitsubishi: F24OAC/F220-VP thermal paper)
¾ Paper roll core diameter: Inside 12 mm, Outside 18mm
Caution:
Please use the recommended paper type or its equivalents. Using the lower quality paper
types may affect the print quality and shorten print head life.
The paper should not be glued to the core.
If the paper is contaminated by chemical or oil, it may discolor or lose heat sensitivity at the
polluted spot.
Do not rub the paper surface strongly against hard objects; it may discolor.
Discoloring starts when temperature is over 70°C. Be careful of effects of heat, humidity, light,
and so on.
- 5 -
