BTP-2002NP User’s Manual
Caution:
Adjust the position of paper guide according to the width of the paper to be used.
Make sure that the beginning of roll paper is cut according to the requirement as
follows before loading:
Make sure that the heat sensitive side of paper faces the print head and the rolling
direction of paper meets the requirements.
The paper should be neatly fitted on the paper roll when loading.
The paper roll should be able to freely roll in the paper cabinet of the printer and not be
stuck as it may cause paper jam or other malfunctions.
3) Pull the beginning of the roll paper out up to the end of the upper cover, then close the
printer cover, as follows:
Caution:
Both sides of the printer cover must be pressed down completely in order to ensure
that the top cover is closed completely.
The paper should leave the paper exit straight and not crumpled as shown in the above
figure.
4) Tear off the surplus portion of paper with the tear off bar.
- 11 -
