socomec MODULYS GP - Page 24

24
MODULYS GP Green Power 2.0 range from 400 to 600 kVA - Ref.: IOMMODGPXX07-EN 00
4-3
4. OVERVIEW
4-4
Coupling cabinet front view
Q80
Manual bypass switch
Q70
Output switch
X70 Output UPS 1-2-3
N-L1-L2-L3 Input mains
PE Ground connection
Switches state contacts
X60-X61-X62
Auxiliary mains UPS1-2-3
X90 Output to load
X80 Auxiliary mains
X200 Battery terminals
A
B
C
